Unmatched operation
- Outstanding temp. uniformity with CerAlTop™ aluminum alloy heating plate
- Excellent resistance to chemicals scratches and surface abrasions
- Maximum temperature 370 °C
- Accepts up to 20 litre flasks
- Electronic speed regulation up to 1500 rpm
- Excellent speed control, even at low speeds
- High power PCM-type driving magnet
Reliable & Precise Results
- SpeedServo™ ensures constant speed even when the viscosity changes
- Digital setting and displays for temperature and time
- Connection for VTF Vertex digital thermoregulator for direct temperature control
- VTF incorporates timer for unsupervised operation and increased productivity
Convenient Format
- Available packaged with probe and VTF
- High visibility LED displays visible from a distance
Sample & User Safety
- Programmable maximum safety temperature
- Hot plate warning displayed while cooling to below 50 °C
- Control panel is IP 42 protected from liquid spills with run-off groove
- Designed for the longest lifespan and guaranteed by 3 years warranty
Ergonomic Design
- Inclined control panel for easy access and visibility
- AluBlocks™ maximize temperature control & save handling time
- Run different tubes by combining AluBlocks™
Choice of Models
- AREX Digital PRO with PT100 probe
- AREX Digital PRO with PT100 probe, Rod and Clamp
- AREX Digital PRO with VTF Vertex digital thermoregulator (+ support rod)
|
|
GENERAL FEATURES
| Construction material | epoxy painted aluminium structure |
| Heating plate: | aluminum alloy coated with ceramic coating |
| Heating plate diameter: | 135 mm |
| Digital display: | one for speed, one for temperature |
| Pt100 connection: | provided |
| Vertex connection: | provided |
| Protection rating CEI EN 60529: | IP 42 |
| Power: | 630 W |
| Weight: | 2.6 Kg |
| Dimensions (WxHxD): | 165x115x280 mm |
| |
| PERFORMANCE | |
| Electronic speed regulation: | up to 1500 rpm |
| Counter-reaction: | constant speed |
| Electronic temperature regulation: | from room temp. to 370°C |
| Maximum safety temperature digitally settable: | temperature limit can be set between 50 and 370 °C |
| Overtemperature safety circuit | Yes |
| "Hot Plate Warning" | whenever the top plate temperature is over 50 °C |
| Sample thermoregulation: | ± 0.5 °C by using the Vertex thermoregulator (AREX Digital PRO);
± 1.0 °C by using Pt100 |
| Stirring volume (H2O): | up to 20 liters |
| Stirring system: | high-power driving magnet type ''PCM'' operated by a mono-phase motor for continuous operation |
| |
|
